Electrical properties:
EVO 3
typ. power consumtption [W]190
power factor> 0,95
input voltage range [VAC]100 – 240/277 50/60 Hz
max. input current [A]0,9@220Vac
typ. inrush current [A]65
Further properties:
EVO 3
weight [kg] 3,5 / 3,8 / 4,1
overall length [mm]468 / 643 / 818
protection ratingIP65
ambient operating temp. [°C] 5 – 35
max. relative humidity [%]99
emission wavelength [nm] 400 – 780
BPF* [µmol/s]520
module efficacy* [µmol/J] >3
angle of radiation [°]90-112
warranty [years]3
LM90 [hours] > 90.000
